Technical data
Operating voltage 24 V AC/DC SELV
Outputs 3 x 0-10 V, 2 x relay 5 A/250 V AC
Measuring range CO2 0 – 2000 ppm
Measuring range temperature +5 °C … +40 °C
Measuring range humidity 30 – 80 % rF
Hysteresis ±75 ppm
ON/OFF thresholds 700 ppm ±200 ppm, 1300 ppm ±200 ppm
Type of connection Screw terminals
Display 6 LEDs
Installation type Wall installation (also on flush-mounted socket possible)
Type of protection IP 20
Protection class II as per EN 60 730-1
